MAI®2PUMP PICTOR-3D
Pocket-sized high performance
- Entry-level model for 3D concrete printing
- Compact and lightweight
- Variable pump capacity
- Robust construction
- Speed adjustment via analog interface
- Easy cleaning and maintenance
- Flexibility and versatility
The MAI®2PUMP PICTOR-3D is a compact and powerful conveying pump that has been specially adapted for 3D concrete printing.
It is perfect for smaller but precise 3D concrete printing applications in laboratories or for innovative start-ups that rely on state-of-the-art printing technologies.
Applications
- 3D concrete printing with premixed, pumpable materials up to 2 mm grain size
Technical advantages
With a delivery rate of 0.7 to 15.5 l/min, the MAI®2PUMP PICTOR-3D pumps materials with grain sizes of up to 2 mm.
The optional hopper with agitator prevents segregation of the material and ensures consistently high quality.
Technical details
- Adjustable delivery rate: The delivery rate can be controlled by the 3DCP-System via an analog interface (0-10V)
- Compact and lightweight: Despite its compact design, the MAI®2PUMP PICTOR-3D offers very high performance
- Robust: The use of MAI®CODUR, stainless steel components and hot-dip galvanized parts guarantee a long service life and reliability
- Easy cleaning and maintenance: The machine can be dismantled very quickly and is easy to clean, which saves time and money
Accessories
Pressure sensor unit with analogue output 0-10V
Hose blockage remover
Hopper with agitator
The MAI®2PUMP PICTOR-3D is not only ideal for use in 3D concrete printing, but also for pumping various premixed mortars and other demanding materials. Our experts are at your disposal.
